Portable Ultrasound US1000

Description:-

US 1000 3rd Edition is an FDA approved portable therapeutic ultrasound unit . New - now with 3 power output settings . Device must be used with ultrasound gel to conduct the ultrasound energy to the skin . Comes complete with ultrasound AC adapter carrying case ultrasound gel and instruction manual . Generates deep heat through a piezoelectric crystal sound head . The piezoelectric crystal converts electrical energy into a strong vibratory sound wave or ultrasound . Sound waves cause vibration in soft tissue cells increasing temperature and inducing vasodilation . Power Source: AC Adaptor (DC 24V/200mA) . Output Frequency: 1.0 MHz +-10% . Temporal Maximum Power: 8W +-10% . Output Intensity: Low 1.6W (0.11 W/cm2) Medium 2.6W (0.24 W/cm2) High 4.6W (0.47 W/cm2) . Duty Cycle: Low 7% Med 15% Hi 30% . Output Mode: Pulse . Pulse Width: 5.4ms +-10% . Repetition Rate: 150Hz +10% . Timer Setting: 30 minutes auto-off +-1% . Weight of unit: 120 g . 6 Month Manufacturer Warranty on unit
